Basic Info.
Model NO.
NS-7080, NS-70105
Structure
General Cylinder
Power
Hydraulic
Standard
Standard
Pressure Direction
Single-Acting Cylinder
Double-Acting Cylinder Type
Common Cylinder
Transport Package
CTN
Specification
steel
Trademark
ENERPAC
Origin
USA, China
HS Code
8412210000
Production Capacity
100, 000PCS/Year
Product Description
NS-Series, Hydraulic Nut SplittersEnerpac hydraulic nut splitters are specially designed to suit standard ANSI B16.5 / BS1560 flangesSingle-acting, spring return cylinderTri-blade technology provides three cutting surfaces on a single bladeInterchangeable heads provide maximum nut range flexibilityPreset scale allows controlled blade extension, which avoids damage to bolt threadsGrip tape and handle included for more secure manoeuvrabilityNickel-plated cylinder body for excellent corrosion protection and improved durability in harsh environmentsInternal Pressure Relief Valve for overload protectionCR-400 coupler and dustcap included on all models.
| Hexagon Nut Range** | Bolt Range | Capacity | Oil Capacity | Model Number* | Weight |
| mm | mm | ton (kN) | cm3 | kg | |
| 70 - 80 | M45 - M52 | 103 (917) | 377 | NS-7080 | 37,0 |
| 70 - 85 | M45 - M56 | 103 (917) | 377 | NS-7085 | 37,0 |
| 70 - 95 | M45 - M64 | 103 (917) | 377 | NS-7095 | 38,5 |
| 70 - 105 | M45 - M72 | 103 (917) | 377 | NS-70105 | 39,5 |
| 110 - 115 | M76 - M80 | 193 (1711) | 819 | NS-110115 | 69,0 |
| 110 - 130 | M76 - M90 | 193 (1711) | 819 | NS-110130 | 71,5 |
