Basic Info.
Model NO.
HP-30
Capacit
300kn
Pressure
25MPa
Piston Travel
200mm
Type
Double Column Hydraulic Press
Certification
CE
Transport Package
Plywood Box
Trademark
SENMO
Origin
China
HS Code
84629190
Product Description
| Hydraulic Press Machine |
| Model | Capacity | Pressure | Piston travel | Table travel | Table size | Dimension | Hydraulic station | N.W./G.W. |
| (KN) | (Mpa) | (mm) | (mm) | (mm) | (cm) | (cm) | (kg) | |
| HP-30 | 300 | 25 | 200 | 270 | 300x400 | 123x55x160 | - | 420/650 |
| HP-50 | 500 | 25 | 220 | 405 | 350x480 | 150x65x195 | - | 980/1100 |
| HP-63 | 630 | 25 | 220 | 405 | 350x480 | 150x65x195 | - | 1020/1500 |
| HP-100 | 1000 | 30 | 250 | 405 | 460x980 | 182x75x225 | 73x63x96 | 1220/1420 |
| HP-150 | 1500 | 30 | 250 | 405 | 460x980 | 184x75x225 | 73x63x96 | 1350/1750 |
| HP-200 | 2000 | 31.5 | 300 | 405 | 500x1000 | 194x95x235 | 90x80x106 | 2200/2400 |
| HP-300 | 3000 | 31.5 | 300 | 405 | 700x1200 | 210x95x270 | 110x120x135 | 4200/4500 |
| HP-400 | 4000 | 31.5 | 300 | 405 | 800x1200 | 230x100x290 | 110x120x135 | 5500/5850 |
| HP-500 | 5000 | 31.5 | 300 | 405 | 900x1200 | 230x100x290 | 110x120x135 | 6500/6900 |
Our Services
What we can do for you?
1. Experienced staffs answer all your questions in time.
2. Customized design is available, more details to let you know our machines well.
3. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staf
